一、外形尺寸及技術參數 Dimensions& T echnicald ata |
XKM/JXH-5A(300×200×140) |
| 訂購數據 Orderngid ata |
外形長/寬/高mm
Exterior length/width/height in illimeters |
600/500/190 |
|
| 材料/materials |
聚碳酸酯/Polycarbonate PC ABS |
| 密封材料/Sealing materials |
氯丁橡膠/Neoprene |
| 工作溫度/Work temperature |
-40℃~+85℃ |
| 防護等級/Protection grades |
IP66 |
顏色/Version
淺灰色/Shallow gray |
訂貨號/Order Number : 110513 | |
| |
|
|
|
