XKM/JXH-4系列接線盒

當前位置:

產品中心

XKM/JXH-4系列接線盒

XKM/JXH-4系列接線盒

如果您有任何問題可以聯系我們!
聯系我們

XKM/JXH-4A(300×200×140)
XKM/JXH-4B(300×250×160)
一、用途 U s e
        用于1000V以下的控制電氣回路中電纜線芯的分支與聚合,是現代工業諸多領域,室內外電氣控制回路的理想裝置。該系列產品可以通過安裝接線端子、電纜接頭、按鈕開關、信號燈等電器件組成電源盒、控制盒、信號盒等裝置。
        It is used for the branching and polymerization of the cable loop in the control electrical return circuit under 1000V. They are the ideal indoor and outdoor electrical control circuit devices in modern industrial areas. The series of products can constitute electrical power boxes, control boxes, signal boxes and other devices by installing connecting terminals, cable joints, button switches or signal lights.
二、特點 F ea tures
電絕緣性能好/Good electric insulation properties
機械強度高/High mechanical strength
阻燃性好/Good fire retardation
耐腐蝕性強/Strong corrosion resistance
工作溫度范圍大/Wide working temperature range
防護等級高/High-level protection
三、外形尺寸及技術參數 D imensions& T echnicald ata
訂購數據 Orderngid ata
外形長/寬/高mm
Exterior length/width/height in illimeters
300/200/140
材料/materials 聚碳酸酯/Polycarbonate
密封材料/Sealing materials 氯丁橡膠/Neoprene
工作溫度/Work temperature -40℃~+85℃
防護等級/Protection grades IP66
顏色/Version
淺灰色/Shallow gray
訂貨號/Order Number : 110494
訂購數據 Orderngid ata
外形長/寬/高mm
Exterior length/width/height in illimeters
300/250/160
材料/materials 聚碳酸酯/Polycarbonate
密封材料/Sealing materials 氯丁橡膠/Neoprene
工作溫度/Work temperature -40℃~+85℃
防護等級/Protection grades IP66
顏色/Version
淺灰色/Shallow gray
訂貨號/Order Number :110495

XKM/JXH-4C(400×300×160)
XKM/JXH-4D(500×400×190)
一、用途 U s e
        用于1000V以下的控制電氣回路中電纜線芯的分支與聚合,是現代工業諸多領域,室內外電氣控制回路的理想裝置。該系列產品可以通過安裝接線端子、電纜接頭、按鈕開關、信號燈等電器件組成電源盒、控制盒、信號盒等裝置。
       It is used for the branching and polymerization of the cable loop in the control electrical return circuit under 1000V. They are the ideal indoor and outdoor electrical control circuit devices in modern industrial areas. The series of products can constitute electrical power boxes, control boxes, signal boxes and other devices by installing connecting terminals, cable joints, button switches or signal lights.
二、特點 F ea tures
電絕緣性能好/Good electric insulation properties
機械強度高/High mechanical strength
阻燃性好/Good fire retardation
耐腐蝕性強/Strong corrosion resistance
工作溫度范圍大/Wide working temperature range
防護等級高/High-level protection
三、外形尺寸及技術參數 D imensions& T echnicald ata
訂購數據 Orderngid ata
外形長/寬/高mm
Exterior length/width/height in illimeters
400/300/190
材料/materials 聚碳酸酯/Polycarbonate
密封材料/Sealing materials 氯丁橡膠/Neoprene
工作溫度/Work temperature -40℃~+85℃
防護等級/Protection grades IP66
顏色/Version
淺灰色/Shallow gray
訂貨號/Order Number : 110496
訂購數據 Orderngid ata
外形長/寬/高mm
Exterior length/width/height in illimeters
500/400/190
材料/materials 聚碳酸酯/Polycarbonate
密封材料/Sealing materials 氯丁橡膠/Neoprene
工作溫度/Work temperature -40℃~+85℃
防護等級/Protection grades IP66
顏色/Version
淺灰色/Shallow gray
訂貨號/Order Number : 110497

XKM/JXH-4C(400×300×160)
注: 根據用戶要求,對可盒蓋、盒體側壁 進行各種開孔加工及元器件組裝,如用戶有特殊要求,我公司將盡力滿足。
Note:
Our company will provide service such as portiforium of the box cover and sides, and assembly of components in accordance to the customer’s requests. We will spare no effort to meet any special demands of our customers.
訂購數據 Orderngid ata
一、外形尺寸 Dimensions
外形長/寬/高mm
Exterior length/width/height in illimeters
600/500/190
二、技術參數 Technicald ata

材料/materials 聚碳酸酯/Polycarbonate
密封材料/Sealing materials 氯丁橡膠/Neoprene
工作溫度/Work temperature -40℃~+85℃
防護等級/Protection grades IP66
顏色/Version
淺灰色/Shallow gray
訂貨號/Order Number : 110498

蜂窩式底板(隨意安裝)
Cellular bottom plate (random installation)
