| 一、產品概述 Genera |
根據電力部電網改造規劃，為了改善居民用電條件，本公司按照市場需要，開發了用于進戶線分線多路輸出接線盒。產品投入市場以來，受到了廣大電能計量工作者的歡迎。既操作方便，又確保了接線的牢固性和可先靠性，達到了安全用電的目的，為計量裝置的標準化和規范化起到了推動作用。
本系列產品經過國家強制認證，各項技術指標均符合GB14048國家標準和IEC國際標準要求。現已被電力部門推廣使用。
According to the power grid upgrading plan, in order to improve residential electricity utilization condition, the company developed the multi-circuit output terminal block for branch lines of service-entrance wires in the light of market demand. The products have been popular with the electric energy measuring operators since being launched on the market, they not only are convenient to operate, but also guarantee fastness and reliability of wiring, finally reach the aim of safety in utilizing electric energy, actively promote the standardization and normalization of metering device.
This series of products has passed the China compulsory certification, the technical indexes are in conformity with national standard GB14048 and international standard IEC, now the products are widely popularized by the power department. |
| 二、結構特點 Structure features |
該產品體積小，載流容量大，耐壓高，結構合理，外形美觀，具有阻燃性，耐高溫，不吸水、抗潮濕、絕緣性能好，抗沖擊、抗老化等多種優質特性。
蓋板采用透明材料，且拆裝方便，達到了透明直觀，安全用電的目的。
Featured with small volume, large current carrying capacity, high withstanding voltage, reasonable structure, nice appearance, etc., this product has many superior properties such as flame retardant, withstanding high temperature, no water absorption, wetness prevention, perfect insulation, impact resistance, anti aging, etc..
Its cover plate is made of transparent material, assembled and disassembled conveniently, so, it attains the goal of transparence and visualization as well as reliable power utilization. |
| 三、 產品用途 Application |
該適用于各種表位計量的配套使用，安裝后不但解決了進戶線直接進裸銅排，造成電流小、不安全、不可靠、不方便等諸多事故隱患的問題，而且減少計量箱的成本。按產品的極數分為單極（1P）、單相（2P）、三相三線（3P）、三相四線（4P）；按出線分為一出、二出、三出、四出…二十四出等。
This product supports metering of various meter-position, after mounting, it not only avoids the problem of weak current, unsafe, inconvenience or other potential accidents caused by service-entrance wire entering into bare copper bar directly, but also cuts down the cost of metering box. It can be divided into single-pole (1P), single-phase (2P),
three-phase three-wire (3P), three-phase four-wire (4P) according to the pole number; it can be divided into one-outlet, two-outlet, three-outlet, four-outlet … twenty-four-outlet and so on according to the outlet wire condition. |
| 四、主要技術指標 Main technical indexes |
1、絕緣電壓Insulation voltage：660V 50HZ(60HZ)
2、進戶線電流(A/截面mm2) : 100/25、150/50、250/120、300/150、400/240
3、進表線電流(A/截面mm2)Meter-entrance conductor current(A/section mm2): 60-125/10-25(每路出線)
4、工頻耐壓Power frequency withstand voltage：3000V/1min
5、工作溫度Working temp.：-40℃～+160℃
6、端子間及絕緣電阻Terminal-to-terminal/insulation resistance:＞40MΩ |
