連接示意圖
Schematic diagram of connection |
 |
單力矩螺母
Single-torque nut GP |
 |
雙力矩螺母
Double-torque nut | |
| 一、產品概述 Genera |
1. 用于建筑配電系統絕緣電纜支接、低壓架空絕緣電纜連接、低壓絕緣進戶電纜支接、路燈配電系統等。
2. 主線：絕緣銅或鋁
3. 支線：絕緣銅或鋁
4. 可帶電或停電作業
5. 穿刺線夾主體采用高強度，抗機械變化和氣候變化的絕緣材料制成。
6. 配有緊固力矩螺母的螺釘經抗腐蝕處理，力矩螺母使安裝更簡便、安全、快捷，其恒定穿刺壓力可確保電纜連接達到需要的電氣效果。
7. 穿刺線夾具有防水功能，可在水中耐受電壓6KV無擊穿現象。
8. 密封防水支線端蓋，可防止水浸入支接導線（防水軟端蓋"GP”為任選項）?？筛鶕?jù)需要左側或右側分支。
1. Used for branch connection of insulated cable for architectural distribution system, connection of LV overhead insulated cable, branch connection of LV insulated service-entrance cable, dist-ribution system of streetlight, etc.
2. Main line: Insulated copper or aluminum
3. Branch line: Insulated copper or aluminum
4. Live-line work or power-cut work is allowable
5. Main body of connector is made of high strength insulating material that anti mechanical change or climatic variation.
6. The screw that is equipped with fastening torque nut is anticorrosion treated, the torque nut en-ables the installation to be much simple, safe and quick, its constant puncturing pressure gua-rantees best electrical effect for the cable connection.
7. The connector is featured with property of waterproof, it is able to withstand voltage of 6KV in water without breakdown phenomenon.
8. The waterproof sealing end cap of branch line prevents water from entering into the branch con- nected conductor(waterproof soft end cap "GP” is optional item). It can be branched on the left or right side according to the demand. |
 |
 |
 |
可左支接
Left branch
connection is available |
可右支接
Right branch connection
is available |
力矩螺母
Torque nut | | |
